TP-420H REMOTE HYDRAULIC CRIMPING HEAD
Product Details
12 tons remote hydraulic crimping head
For connector or cable lug crimping
Remote type needs to work with pump
TP-420H (Remote Type)
6-400mm2 (AWG10-750MCM)
hexagon crimping range
42mm C-jaw opening
12 tons output / 5.3kgs / 250mm
Standard dies (10pcs)
35/50/70/95/120/150/185/240/
300/400mm2
(i.e. B3035-B30400, R30 type)
Standard dies (10pcs)
35/50/70/95/120/150/185/240/
300/400mm2
(i.e. B3035-B30400, R30 type)
35/50/70/95/120/150/185/240/
300/400mm2
(i.e. B3035-B30400, R30 type)
TP-420H (Remote Type)
6-400mm2 (AWG10-750MCM)
hexagon crimping range
42mm C-jaw opening
12 tons output
6-400mm2 (AWG10-750MCM)
hexagon crimping range
42mm C-jaw opening
12 tons output
| Model No. | Application | Standard dies | Output | Crimping range supported | Length | Weight | C-jaw opening | Remark |
|---|---|---|---|---|---|---|---|---|
| TP-420H | For connector or cable lug hexagon crimping | Standard dies (10pcs) 35/50/70/95/120/150/185/240/ 300/400mm² (i.e. B3035-B30400, R30 type) | 12 tons | 6-400mm² (AWG10-750MCM) | 250mm | 5.3kgs | 42mm | Remote type, C-head |
